12V dc high speed blower WS7040-12-X200
product parameters
| Products model | WS7040-12-X200N | WS7040-24-V200 |
| Voltage | 12VDC | 24VDC |
| Max.air pressure | 6.0KPA | 6.5KPA |
| Max.air flow | 14.7CFM | 15CFM |
| Noise level | 50-73 DBA | 50-73 DBA |
| Speed level | 35000-43000RPM | 35000-43000RPM |
| Motor type | THREE PHASE BRUSHLESS | THREE PHASE BRUSHLESS |
| Bearing type | NMB BALL BEARING | NMB BALL BEARING |
| Dielectric Strength | 500VDC FOR 1 MIN | 500VDC FOR 1 MIN |
| Protect Class | IP20 | IP20 |
| MTTF | 20000HOURS | 20000HOURS |
| Driver type | WS1208DY01V03-SRP008 | WS2403DY01V04 |
Drawing
- Do not use max pressure as working point,this point is not safe since airflow is too small.
- To add a filter onto the inlet can make the blower run longer time.
- The right impeller run direction is CCW
Product Decription
1. Our medical air blower boasts mature manufacturing technology with over 15 years of experience, providing a competitive edge for our company.
2. Equipped with NMB bearings imported from Japan and a three-phase, brushless DC motor, this product is enclosed in plastic yet has been market-tested and proven to be highly reliable. In a clean environment of 25°C, its lifespan can reach up to 20,000 hours.
3. This product has obtained CE, ETL, ROHS, REACH, and ISO certifications, ensuring its quality and safety.
DC brushless blower advantage
A medical brushless DC air blower has numerous advantages over traditional air blowers. Firstly, it operates quietly and smoothly, which is essential in medical settings where noise can be disturbing to patients. Secondly, it produces consistent air flow, which is crucial in medical equipment that requires a steady flow of air to ensure accurate readings. Additionally, brushless DC motors are more energy-efficient than traditional motors, resulting in lower energy costs and reduced environmental impact.
Furthermore, brushless DC air blowers are low-maintenance due to the absence of brushes that wear down over time, reducing the need for frequent replacements. They also have a longer lifespan than traditional air blowers due to their durability and sturdier construction.
company profile
Company Profile
Our free service hotline:+86-153-3668-6038
15
years
We have been working in the industry since 2009
17
certificates
We have obtained most of the professional certificates in the industry and insist on international standards of production.
2
awards
We are rated as a high-tech enterprise with strong creativity
Earned a national high-tech enterprise & Brushless fan engineering (technology) center
Expand the plant scale and settle in the industrial park
Obtained ISO9001 system certification;
Attract new teams and implement the whole manufacturing process according to standardized & streamlined production
The company is formed
FAQ:
Q: Do you also sell controller board for this blower fan?
A: Yes, we can supply adapted controller board for this blower fan.
In medical ventilators, the system pressure (flow resistance) varies significantly during ventilation.As a result, it is difficult to control the flow rate if the magnitudes of the current flow rate and of expected system pressures are not known in advance with a good enough accuracy. The current system pressure can be measured and be used in a feedback control loop to control the blower via its electronic control circuitry. However, the system pressure changes in dependence on the actual flow rate, and the work point of the blower will change as well, responding to the fluctuating system pressure.This will cause instabilities in the medical ventilator, as a result of limits to the accuracy of the pressure sensor, the dynamic behavior of the sensor, etc., which in turn lead to unstable and inaccurate flow rate control.
Various systems are known in the art that control the flow. Conventionally, the gas flow rate is controlled by actuation of a gas flow valve. Together with a combination of a feed-forward flow control gain component and/or a feedback error correction (e.g., a proportional, integral and derivative error feedback control), this gives rise to the required response.
Another known method to control the gas flow rate is to make explicit use of the properties of the blower. Controllably varying the speed of the blower can be used to control the flow, based on the predetermined relationship between the system pressure and the flow rate.The blower is designed to respond quickly to a change in inspiration or expiration by means of minimizing its inertia. In this case, a feedback controller can be used as well for control of the gas flow. However, variations in the system pressure can change the flow rate, even at a constant blower speed. This problem cannot fully be solved with feedback control. The continuously changing system pressure usually leads to an unstable system or oscillations around the target flow.
